YGL120C Vertical pipe straightener

Pipe straightener machine YGL120C vertical straightener is a machine that rolls are horizontal cross disposed and with double travel driving. The die of rollers is elliptical curve, to ensure therer's no defection on the surface of pipe like helical impress andnick while improve section elliplicity, used to straighten camber of all kinds of pipes (rods). Technical parameter No. Spec.Parameter YGJ120C1Pipe OD(mm) Φ40 Φ1202Pipe WT(mm) 2 163Pipe Max. yield strength(N/mm2) 4904Roller Diameter(mm) Φ2405Roller Length(mm) 3806Roller Distance(mm) 7207Roller angle adjustment(Degree) 25° 29°8Straightening speed(m/min) 259Precision straightening(mm/m) ≤1.510Allowed before bending degree of straightening(mm/m) ≤3011Motor type Z4-225-1112Motor power(KW) 45×213Main motor rotate speed(rpm) 75014Lifting motor type Z4-225-1115Lifting motor power(KW) 3×1.516Lifting motor rotate speed(rpm) 140017Cycloid pin wheel reducer type BLY-2215 i=28918Disposal of roller 2-2-2-119Profile size(mm) 6900×2600×305020Total weight(kg) 22500
